XM7015HD-5 KV:330, 350 gram

Specification

RPM/V (KV): 330
Weight w/o wires(g): 350
Diameter(mm): 69
Length(mm): 39,5
Diameter of Shaft(mm): IN:8.0, Out:4.0mm
Mounting holes pitch(mm): (A)15mm, 4-M3, (B)20mm, 4-M4, 30mm, 4-M4
Slots,Poles: 24, 28
Idle Current(Io) @10V(A): 1,8
Resistance(Ri)(mOhm): 42
Nominal Voltage : 22.2V, 6S Lipo
Cruising power(W)[8 mins]: 810
Bursts current(A)[15s]: 67
Peak power(W)[15s]: 1480
Input Wire : 16AWG, 800mm
Recommended ESC: PCU 60
Propeller : MPR 20"
Water & dust proof - : IP34
Weight of quad-copter(kg): 9,0
Weight of hex-copter(kg): 13,5
Weight of Oct-copter(kg): 18,1
